IMPORTANT! All prices for steel buildings are indicative and given for preliminary acquaintance with the approximate budget for the construction of your building. Nothing is fixed until agreed and confirmed in regards to all technical details of a cetain client's project. Too many factors affect the price level (combination of climatic zones, building dimensions, floating prices for raw materials, labor costs in different countries, bay spacing betweek steel frames, availability of geo-survey work, non-standard loads on walls and roofs, etc.) For more accurate calculation, use the free WebSteel online system (online accounting of the costs and availability of materials at the factory’s warehouse, certain design schemes and solutions) or make a detailed request for a price proposal at the Russian factory in Tula
| Services | Length, m / bay spacing, 6 m. | |||||
|---|---|---|---|---|---|---|
| With 20% VAT. Delivery – EXW. Snow – 210 kg/sq.m., Wind – 23 kg/sq.m., Seismicity – up to 6 points. | 30 | 36 | 42 | 48 | 54 | 60 |
| Delivery terms for assembly and civil work, months (steel framing and cladding, assembly drawings, technical passport and certified engineering calculations) |
1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 |
| Terms of Foundation and installation works, months. | 2 | 2 | 2 | 2 | 2 | 2 |
| Steel framing, RUB. (1 storey, No crane beam, Single span, Gable, with bolts, 100% bolted connections) |
891588 | 1133396.4 | 1290252 | 1447108.8 | 1603964.4 | 1760820 |
| Cladding system, RUB. (profiled sheet), shaped elements, fasteners |
610708.8 | 711445.8 | 812183.4 | 912920.4 | 1013658.6 | 1114395.6 |
| Foundation work, RUB. (pier, base beam included, insulated brickwork – 0.4m high) |
450688.8 | 553452.6 | 630730.2 | 708008.4 | 785286.6 | 862564.2 |
| Concrete floor, RUB. (thickness-150mm, loads - up to 2 tones / sq.m., with reinforced topping - a streamlined top layer of concrete) |
555849.6 | 682591.2 | 777900.6 | 873210.6 | 968520 | 1063829.4 |
| Assembly, RUB. (there are access roads, process technical water, electricity and a fence, cramped conditions are absent) |
405619.8 | 498106.8 | 567657 | 637207.8 | 706758 | 776308.2 |
| Number of Euro trucks, pieces | 3 | 3 | 3 | 4 | 4 | 5 |
| DELIVERY, RUB. (ground, up to 200 km) |
24000 | 24000 | 24000 | 32000 | 32000 | 40000 |
| Total from: | 3457435.2 | 4244422.6 | 4833565.8 | 5430710.8 | 6019854.6 | 6616996.8 |
| Panel view | Thickness, mm | Price, руб/m2 (inclusive of VAT 20%) | |
|---|---|---|---|
| With mineral wool | With polyisocyanurate foam (PIR) | ||
|
Roof panel
|
40 | 778 | 1490 |
| 50 | 973 | 1625 | |
| 60 | 1167 | 1687 | |
| 80 | 1329 | 1850 | |
| 100 | 1429 | 2026 | |
| 120 | 1509 | 2201 | |
| 150 | 1632 | 2490 | |
| 200 | 1945 | 2714 | |
|
Wall panel
|
40 | 1130 | 1325 |
| 50 | 1168 | 1418 | |
| 60 | 1210 | 1507 | |
| 80 | 1295 | 1686 | |
| 100 | 1390 | 1861 | |
| 120 | 1470 | 2054 | |
| 150 | 1593 | 2330 | |
| 200 | 1895 | 2832 | |
Main products of PK Vesta are manufactured at our own factory without intermediaries
PK VESTA is an industrial IT company, which offers free online design, manufacturing and assembly of prefabricated steel buildings, as well as sandwich panels, gates and doors. We've been in business since 1991. Make a unique design of your steel building online in WebSteel and we will make a custom building kit shipped worldwide.
